1,000 Watt Class-bd 5-Channel Amplifier
The PM1000X5 is a 500 Watt 5-channel amplifier with high dynamic power using Class-a/b technology on the front/rear channels, Class-bd for the subwoofer channel, and a conformal coated pc board designed for motorsport and marine applications.
- High level input capable with Auto Turn-On circuit
- Features C.L.E.A.N. Set-up
- Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
- 12dB/octave Butterworth crossover
- On-board Punch EQ with +18dB boost @ 45Hz.
- Muted turn on
- Stealth top mounted control panel
- Cast aluminum heatsink
- Short circuit protection
- Over current protection
- Infrasonic filter
- 2/4 channel input switch
- Marine grade two part epoxy coating on circuit boards
- Marine grade stainless steel hardware
| CEA-2006 Compliant: |  CEA-2006 Power Rating
75Wx4 + 150Wx1 @ 4Ω
≤1.0% THD+N |
Rated Power
(RMS Continuous Power): | 75 Watts x 4 +
150 Watts x 1 @ 4-Ohm
125 Watts x 4 +
300 Watts x 1 @ 2-Ohm
N/A +
500 Watts @ 1-Ohm |
Total Power
(Sum of Rated Power): | 1000 Watts |
Dynamic Power
(PVC/PowerCube®): | 115 Watts x 4 +
299 Watts x 1 @ 4-Ohms 0° Res
190 Watts x 4 +
540 Watts x 1 @ 2-Ohms 0° Res
N/A +
863 Watts x 1 @ 1-Ohm 0° Res |
| Bridgeable: | Yes (front/rear channels) |
| Frequency Response: | Front/Rear: 20Hz - 20kHz +/-3dB
Sub: 20Hz - 500Hz +/-3dB |
| Efficiency (average): | Front/Rear: 66% @ 4-Ohm
Sub Channel: 80% @ 4-Ohm |
| Total Harmonic Distortion(THD+Noise): | <1.0% |
| Crossover Controls: | Front: 50Hz - 250Hz High-Pass @ 12dB/Octave
Rear: 50Hz - 250Hz High-Pass @ 12dB/Octave
Sub: 50Hz - 250Hz Low-Pass
Sub: 28Hz infrasonic filter @ 12dB/Octave |
| Tone Controls: | Sub:
0dB to +18dB @ 45Hz |
| Input Sensitivity: | 150 mV - 12 V |
| Signal Input: | Input Switch: Hi/Low level input
Input Switch: 2/4 channel input
Hi/Low Level: 3 RCA Pair
Sub: front/sub input switch |
| Power Input Connector: | Block |
| Speaker Output Connector: | Block |
| Speaker Wire Gauge: | 12 AWG |
| Remote Controls: | Optional Punch Level Control (PLC2) Ready |
| Visual Indicators: | Power/Protect/Thermal LED
Input Clip LED
Output Clip LED |
| Circuit Topology Class: | Front/Rear: Class-A/B
Sub: Class-BD |
| Operating Voltage: | 9 - 16 VDC |
Recommended Fuse
(not included): | 150 A |
| Max. Current Draw (13.8V Sinewave): | 150 A |
| Average Current Draw (13.8V Music): | 75 A |
| Suggested Alternator: | 100 A |
| Shipping Weight: | 15.3 Lbs. (6.93 Kg.) |
| Dimensions (H x W x D): | 2.38 x 7.76 x 15.03 (in)
6.05 x 19.71 x 38.18 (cm) |
| Dimensional Diagram: |  |
